AMG IE2 High Efficiency Steel Frame Motors
Specifications
Efficiency: IE2 High Efficiency
Construction: Fabricated Steel Frame Totally Enclosed Fan-Cooled (TEFC)
Output power: 7,5kW 4P, 15kW 4P, 22KW 2 P, 37kW 2P & 45kW 4P
Frame size: 132-250
Speed: 2 & 4 Pole
Voltage: △ 525-550-575V
Winding: H Class insulation, B Class temperature rise
Mounting: B5 Flange Mounted
IP rating: IP65
Compliance: SANS 1804-1/2 – IEC60034-1-2
Application: Vertical Spindle Pumps – Heavy Duty Mining
FEATURES & BENEFITS
- Oversized bearings
- Lamination steel, high quality silicon steel
- Fully wedged stators throughout entire range
- All motors are fully vacuum pressure impregnated (VPI)
- 1 year warranty
- Rotor – Die Cast Aluminium
